The small 18 horsepower Postal tractor is a small belt-driven tractor designed especially for farm work in the yard.
Advantages of the small 18 horsepower postal tractor:
· The differential lock can increase grip.
· based on a solid motorized tractor chassis.
· Worm steering system, with excellent mobility.
· Whole tractor gearbox, reliable performance.
· Equipped with rearview mirrors and front fenders to ensure safety.
· The dashboard includes an oil pressure gauge, a coolant thermometer, and an ammeter.
· Two-section hydraulic dispenser for connecting various accessories.
The main tasks of the postcard 18 horsepower small tractors are:
· ploughing, tillage.
· sowing and harvesting with seeders and excavators.
· Use a lawn mower to mow the lawn, including a rotary lawn mower.
· Use snow to eradicate snow.
· Transport of goods by trailer.
Why choose a small 18 horsepower tractor post?
This economical and reliable small tractor is made in China by postcards and is very popular in China and Eastern Europe. With high-quality components and strict production quality control, it ensures durability and high performance.
Advantages of this model:
1. Reliable diesel engine, efficient performance.
The di-em 2.40 direct injection system improves combustion efficiency and reduces fuel consumption (1.2 - 2 liters per hour) and noise.
3. Planetary center differential increases flotation and minimizes wheel wear.
4. Multifunctional hydraulic system with four operation modes: forced lowering, locking, floating and forced lifting.
5. Durable 2-beam welding frame to create a solid chassis.
6. Compared with similar models, the extended base has better stability.
7. The driver's position is comfortable, the control device and pedal position are good.
8. Adjustable tracks from 1080 mm to 1450 mm.
9. The durable V-belt can last up to 3,000 hours under proper tension.
10. Durable, smooth and easy-to-engage dry disc clutch.
11. High quality cast iron gearbox housing, with magnesium added, earthquake-proof; Shaft made of alloy steel to increase strength.
12. The redesigned front axle steering system allows for tighter turns and improves steering comfort.
13. AISIN oil seal can prevent oil leakage in the bridge even under continuous vibration.
14. High hydraulic cylinder to avoid dirt and dust.
15. Universal hooks allow compatibility with equipment from various manufacturers.
16. The reinforced hook design improves the durability of attachments under heavy load, including soil cultivator.
17. A variety of starting options, including electric start and pressure reducing valve, make it easy to start the engine.
The small 18 horsepower Postal tractor is an excellent choice for those looking for multifunctional, durable, and economical solutions to perform various agricultural and landscaping tasks.
18hp Small Chinese Tractor
The 18 horsepower small tractor is a powerful and versatile small tractor, equipped with an 18 horsepower diesel engine, with better performance, ideal for challenging roads such as soft or swampy terrain. The model is designed to offer outstanding traction and durability, comparable to 20hp gasoline engines at low speeds.
Key features:
· Powerful Diesel Engine: The 18-horsepower engine has excellent fuel efficiency, low-speed traction, and high durability, ensuring long-term operation.
· Heavy frame: After reinforcement, it is easy to connect heavy tools, has a solid drive shaft, and can withstand maximum load.
· Hydraulic system: double cutter and idle perforated drive chain, with longer service life. Equipped with 2-vector hydraulic system, it can be connected and used at the same time.
· Engine cooling: The liquid cooling system can achieve uninterrupted operation for up to 10 hours.
· Wide range of uses: The width of the track can be adjusted from 1000mm to 1200mm, which is ideal for planting and cultivation, and the electric start can ensure reliable performance in cold weather.
· 6-speed transmission: 3 forward gears and 2 reverse gears, which can be easily accelerated to 40 km/H.
Improvements to improve efficiency:
· Extended hydraulics: Two attachments can be connected at the same time, reducing operation time and being well suited for municipal tasks.
· Durable Construction: The Robust Gearbox is made of Q500 cast iron, which is one of the hardest materials today.
· Low maintenance cost: Due to high-quality components, the failure rate is the lowest, and it is easy to get affordable spare parts.
Operational flexibility:
· The accessories can be used for cultivation, ploughing, lawn mowing, harvesting, etc.
· It can also be used as a fixed power supply for irrigation or drainage.
Improve operator comfort:
· Track Adjustment: The track width can be easily adjusted between 105 - 140 cm to make it suitable for tasks such as potato cultivation and interpositional processing.
· Updated instrument panel: Digital display and electronic ammeter including coolant temperature, oil pressure for easy monitoring.
Economical, efficient and reliable:
The postal tractor is famous for its affordable price and high quality, and the return on investment is very high. The 18 horsepower mini tractor is designed for various conditions, from gardens to farmland, and can even be transported short distance with trailers.
Why choose a small 18HP postal tractor?
· Compact, flexible and reliable.
· Specially designed for drylands, mountainous areas, etc.
· Provide a variety of accessories.
· Easy-to-operate, easy-to-change tools and optional colors in different markets.
Parameters:
Model | Tractor AL130 | Tractor AL150 | Tractor AL180 | Tractor AL200 |
Overall Dimensions:(L×W×H) | 2140×905×1175mm Without Rotary Cultivator |
Overall Dimensions:(L×W×H) | 2600×1000(1200)×1175mm With rotary cultivator |
Front Wheel Size | 4.00-8 (4.00-12, 4.00-14, 5.00-12) |
Rear wheel size | 5.00-12 (6.50-16, 7.50-16) |
Ground clearance | 180mm |
Working weight (with rotary tiller) | 485kg | 490kg | 530kg | 540kg |
Working weight (without anything) | 400kg | 405kg | 445kg | 455kg |
Transmission Type | V-belt tension |
V-belt model | B3200 |
Leadership style | Power steering wheel steering |
Brakes | Two-wheel side brake |
Beginning | Electric Start/Crank |
Seat | Adjustable |
Gear Style | (3+1)*2; 6 forward, 2 backward |
Velocity | Go ahead | 1.68, 2.61, 4.22, 6.79, 10.57, 17.08 |
| Invest | 1.29, 5.22 |
Tiller | Transmission Type | Center or side drive |
| Width | 1000-1200mm |
| Number of blades | 18-22 pcs |
| Working depth | 100-180mm |
| Upload and Descent Control | Hydraulics |
Engine | Model | 12NDL | 13NDL | 15NDL | 16NDL |
| Guy | 1 cylinder, 4-stroke, horizontal, water-cooled, diesel |
| Cooling Mode | Condenser (Radiator) |
| Rated Power | 8.82kw/15hp | 9.55kw/13hp | 11.03kw/15hp | 11.76kw/16hp |
| Combustion system | Swirl or direct injection |
| Cylinder bore | 92mm | 92mm | 95mm | 100mm |
| Piston stroke | 90mm | 95mm | 98mm | 100mm |
| Compression ratio | 18:01 |
| Rated Speed | 2400rpm |
| Fuel efficiency: | ≤2264gl/kw.hr | ≤257gl/kw.hr | ≤245gl/kw.hr | ≤240.2gl/kw.hr |
| Displacement | 0.598L | 0.632L | 0.695L | 0.785L
|
