Configuration & Features
(1) The power adopts Loncin gasoline engine, oil-electric hybrid, with its own power generation and power supply system, and automatic charging during the working process.
(2) The motor adopts a brushless DC motor of CNC machine tools, which is energy-saving and durable, and suitable for long-term work.
(3) Automatic braking when stopping, suitable for steep slope operation.
(4) The generator is a marine-grade generator, with a very low failure rate and long life.
(5) The control adopts industrial remote control device, which is simple to operate, low failure rate, and the remote control distance is 200 meters.
(6) The track is made of internal steel frame steel wire, and the external engineering rubber is designed, which is wear-resistant and durable.
(7) Strengthened chassis, low fuselage, tank-like design, climbing and ditching are strengths; Ideal for: embankments, orchards, hills, terraces, photovoltaics, and green mowing.
(8) Adjustment: The height of the grass is 3-15 cm, and the mowing speed is adjustable by remote control.
Technical parameters
serial number | The name of the project | unit | Parameter value |
1 | host | Model | | ALK80-2B-1P |
Dimensions (L×W×H) | mm | 1180*1230*550 |
Structural quality | kg | 280 |
Track width | mm | 120 |
2 | Supporting power | Manufacturers | | Loncin General Dynamics Co., Ltd |
Model name | | LC1P92F-1 |
Structural type | | Horizontal bar four-stroke |
Rated power | Ps | 16 |
Rated speed | r/min | 3600 |
Type of fuel | | gasoline |
Average fuel consumption | L/h | 1.5-2 |
Displacement | cc | 452 |
3 | Travel motor | Rated power | Kw | 1.6 |
Operating voltage | V | 48 |
rotate speed | r/min | 1000~3000 |
Walking speed | Km/h | 0~5 adjustable |
Remote control distance | m | ≤200 |
The working slope | Degree | ≤50 |
4 | dynamo | Rated power | kw | 5 |
5 | accumulator | Battery type | | Dry batteries |
Walking battery voltage | V | 48 |
Walking battery capacity | Ah | 20*4 |
Charging type | | The generator is automatically charged when it is working |
6 | Matching mowing knives | Number of knives | slice | 2 |
Tool speed | r/min | 2500~3000 |
Mowing width | mm | 800 |
Grass height | mm | 30~150 adjustable |
Load capacity | Kg | ≤400 |
